NaI(Tl) scintillators Standar sizes
NaI(Tl) scintillators are available with either a circular or square cross-section and housed in rugged, hermetically sealed aluminium or titanium windowed cylinders. Sizes up to 125mm Diameter by 100mm Thicknesses are available.
ASC1101-01
13x30
16.5
17
35.5
ASC1101-02
20x20
25
26
26
ASC1101-03
20x40
25
26
46
ASC1101-04
30x15
35
36
21
ASC1101-05
30x20
35
36
26
ASC1101-06
30x25
35
36
31
ASC1101-07
30x30
35
36
36
ASC1101-08
30x50
35
36
56.5
ASC1101-09
40x25
45
46
31
ASC1101-10
40x30
45
46
36
ASC1101-11
40x40
45
46
46
ASC1101-12
40x50
45
46
56.5
ASC1101-13
50x30
55
56.5
36.5
ASC1101-14
50x50
55
56.5
57
ASC1101-15
50x60
55
56.5
67
ASC1101-16
75x50
81
82.5
57
ASC1101-17
75x75
81
82.5
82
ASC1101-18
100x50
110
112
58
ASC1101-19
100x100
110
112
108
ASC1101-20
125x50
135
137
60
NaI(Tl) scintillators are available in a wide range of ‘standard sizes’ as listed here. These NaI(Tl) scintillator products feature circular cross-section scintillator crystal and are of a ‘rim-less’ format. Each variant can be supplied with a ‘rim’ to aid and facilitate interfacing to a detector. The rimmed variants are designated with an R, for example the first item would be designated as ASC1101-R-01.

L = Length
D = Diameter along length of housing
D1 = Diameter at sealing flange

Other dimensions are possible and can be made to order.

In addition square cross-section crystals can be supplied in these housings.
